Grade 304 30 Micron Dutch Stainless Woven Wire Mesh High Precision

Brand Name : R&K

Model Number : Dutch-11

Certification : SGS

Place of Origin : Hebei,China

MOQ : 1 squaremeter

Price : Negotiate

Payment Terms : L/C, T/T, Western Union，PayPal

Supply Ability : 1000 squaremeter per week

Delivery Time : 5-8 work days

Packaging Details : Inside with paper tube,Then waterproof paper covered,Finally in a wooden case or pallet

Product name : Grade 304 30 Micron Dutch Stainless Woven Wire Mesh High Precision

Material : Stainless steel woven mesh

Type : Weave wire mesh

Hole shape : Square shape

Application : Screen

Technique : Woven

Feature : Acid resistant

Hole : 30 micorn

Contact Now

Grade 304 30 Micron Dutch Stainless Woven Wire Mesh High Precision

Product name	304 High Precision 30 Micron Stainless Steel Dutch Woven Wire Mesh
Type	Stainless steel Dutch Woven wire mesh
Diameter	0.015 - 0.9mm
Hole Size	3 -347 micorn
Material	low carbon steel wire, brass wire, nickel wire, stainless steel wire, polyester fiber
Mesh Count	7-3500 Mesh
Usage	Protection mesh,filter
Color	Silver
Size	Customized
Sample	Avaliable
Packing	Individually packed in waterproof plastic bags
MOQ	1 meters
Delivery Tim	8-14 days
Processing Service	Decoiling
Length	30m/roll
Width	1.0m
Weaving	plain weave stainless steel dense mesh (plain-dense), twill weave stainless steel dense mesh (twill-dense), bamboo flower woven stainless steel dense mesh, contrast woven stainless steel dense mesh (also known as contrast mat type mesh conveyor belt )
Processing Service	Plain Dutch Weave: Plain weave is similar to row weave. The difference is that the warp of this woven mesh is thicker than the weft. The weft threads are closely spaced together to form conical or wedge-shaped openings
Package	carton
Application		For filters or sieves, such as fuel filters, vacuum filters, cast film filters, sewage treatment;	Serving petroleum, aerospace, metallurgy, food, pharmaceutical and other industries;	Conveyor belts for washing machines, dryers and sludge presses.
Feature	Performance: acid resistance, alkali resistance, high temperature resistance, strong tensile force and wear resistance, stable filtration performance, fineness, high precision, and special filtration performance.

Parameters of stainless steel Dutch mesh

Mesh (mesh/inch) Warp×Weft)	Warp×Weft) mm	Aperture Size (um)	Effective section rate (%)	Weight (kg/m2)	Thickness (mm)
7×,40	0,9×,0,71	347	14.3	6.65	2.32
7×,44	0,71×,0,63	319	14.2	5.55	1.97
8×,45	0,8×,0,6	310	15.5	5.7	2
8,5×,60	0,63×,0,45	296	20.3	4.16	1.53
8×,85	0,45×,0,315	275	27.3	2.73	1.08
10×,90	0,45×,0,28	249	29.2	2.57	1.01
10×,76	0,5×,0,355	248	21.8	3.24	1.21
12×,86	0,45×,0,315	211	20.9	2.93	1.08
12×,64	0,56×,0,4	211	16	3.89	1.36
12,5×,76	0,45×,0,355	192	15.9	3.26	1.16
14×,100	0,40×,0,28	182	20.3	2.62	0.96
14×,110	0,355×,0,25	177	22.2	2.28	0.855
14×,76	0,45×,0,355	173	14.3	3.33	1.16
16×,100	0,4×,0,28	160	17.7	2.7	0.96
17×,120	0,355×,0,224	155	22.4	2.19	0.803
16×,120	0,28×,0,224	145	19.2	1.97	0.728
20×,140	0,315×,0,20	133	21.5	1.97	0.715
20×,170	0,25×,0,16	130	28.9	1.56	0.57
20×,110	0,355×,0,25	126	15.3	2.47	0.855
22×,120	0,315×,0,224	115	15.5	2.2	0.763
25×,140	0,28×,0,2	100	15.2	1.96	0.68
24×,110	0,355×,0,25	97	11.3	2.6	0.855
28×,150	0,28×,0,18	92	15.9	1.87	0.64
30×,150	0,25×,0,18	82	13.5	1.79	0.61
30×,140	0,315×,0,20	77	11.4	2.21	0.715
35×,190	0,224×,0,14	74	16.8	1.47	0.504
35×,170	0,224×,0,16	69	12.8	1.62	0.544
40×,200	0,18×,0,135	63	15.4	1.24	0.43
45×,250	0,16×,0,11	56	15.2	1.11	0.384
50×,300	0,16×,0,09	55	20	0.98	0.34
60×,500	0,14×,0,055	51	34.1	0.7	0.252
50×,270	0,14×,0,10	50	15.2	0.98	0.34
70×,930	0,10×,0,03	30	36.2	0.39	0.16
65×,390	0,125×,0,071	42	19.1	0.78	0.267
60×,300	0,14×,0,09	41	14.1	0.96	0.32
80×,700	0,125×,0,04	40	38.1	0.6	0.205
60×,270	0,14×,0,1	39	11.2	1.03	0.34
77×,560	0,14×,0,05	38	27.5	0.74	0.24
80×,600	0,1×,0,045	37	29.8	0.53	0.19
70×,390	0,112×,0,071	37	16.3	0.74	0.254
65×,750	0,10×,0,036	36	37.1	0.43	0.172
70×,340	0,125×,0,08	35	13.2	0.86	0.285
80×,430	0,125×,0,063	32	16.6	0.77	0.251
100×,1200	0,063×,0,023	23	37.6	0.27	0.109
118×,750	0,063×,0,036	23	21.5	0.38	0.135

Description of stainless steel Dutch woven wire mesh

The scientific name of the stainless steel mat mesh is dense mesh, and it is also called Helan cloth in the south of the Yangtze River or abroad. It is woven with stainless steel wire.Dutch steel wire cloth is also called filter cloth or micro cloth.
